Rating: <UL>
Current: 2 to 40A
Voltage: 250 or 125V AC, 32V DC, 50 to 60Hz</UL>
Dielectric strength: 1, 500V AC/minute
Reset overload capacity: 10-time of rated current
Voltage drop: < 0.25V
Insulation resistance: More than 500MΩ
Temperature rise at terminal block: < 60° At 100% of rated current applied continuously at 23° C
Contact endurance: 125V AC X 150% of rated current, more than 500-cycle
Current: 2 to 40A
Voltage: 250 or 125V AC, 32V DC, 50 to 60Hz</UL>
Dielectric strength: 1, 500V AC/minute
Reset overload capacity: 10-time of rated current
Voltage drop: < 0.25V
Insulation resistance: More than 500MΩ
Temperature rise at terminal block: < 60° At 100% of rated current applied continuously at 23° C
Contact endurance: 125V AC X 150% of rated current, more than 500-cycle
